15 1/2” 15 34.0 6.0 10 442 282 442 283

20 3/4” 20 34.0 11.0 10 442 321 442 322

25 1” 25 50.5 16.0 10 442 368 442 369

40 1 1/2” 40 50.5 29.0 10 442 426 442 427

50 2” 50 64.0 50.0 7 442 481 442 482

Handwheel PPS/bonnet stainless steel

15 1/2” 15 34.0 6.0 10 441 037 441 038

20 3/4” 20 34.0 11.0 10 441 041 441 042

25 1” 25 50.5 16.0 10 441 045 441 046

40 1 1/2” 40 50.5 29.0 10 441 049 441 050

50 2” 50 64.0 50.0 10 441 095 441 096

Acc. DIN 32676, diaphragm material PTFE/EPDM

Handwheel PPS/bonnet PPS

15 1/2” 15 34.0 6.0 10 441 862 441 863

20 3/4” 20 34.0 11.0 10 442 179 442 180

25 1” 25 50.5 16.0 10 442 183 442 184

40 1 1/2” 40 50.5 29.0 10 442 187 442 188

50 2” 50 64.0 50.0 7 442 191 442 192

Handwheel PPS/bonnet stainless steel

15 1/2” 15 34.0 6.0 10 441 023 441 024

20 3/4” 20 34.0 11.0 10 441 069 441 070

25 1” 25 50.5 16.0 10 441 127 441 128

40 1 1/2” 40 50.5 29.0 10 441 181 441 182

50 2” 50 64.0 50.0 10 440 981 440 982Port connection

DN [mm]

ISO 2852 / SMS 3017 BS4825 DIN 32676

8 TC51=Clamp 34 - for tube ISO 4200 TG41=Clamp 25 - Tube 9.53x1.2

10 TC41=Clamp 34 - for tube ISO 4200 TH42=Clamp 25 - Tube 12.7x1.2 TD41=Clamp 34 - Tube 13x1.5

15 TC42=Clamp 34 - for tube ISO 4200 TH43=Clamp 25 - Tube 19.05x1.2 TD42=Clamp 34 - Tube 19x1.5

20 TC43=Clamp 50.5 - for tube ISO 4200 TD43=Clamp 34 - Tube 23x1.5

25 TC44=Clamp 50.5 - for tube ISO 4200 TG44=Clamp 50.5 - Tube 25.4x1.65 TD44=Clamp 50.5 - Tube 29x1.5

40 TC46=Clamp 64 - for tube ISO 4200 TG45=Clamp 50.5 - Tube 38.1x1.65 TD46=Clamp 50.5 - Tube 41x1.5

50 TC47=Clamp 77.5 - for tube ISO 4200 TG46=Clamp 64 - Tube 50.8x1.65 TD47=Clamp 64 - Tube 53x1.5
