the L2 Series has several optional

features. Flow divider and tandem

backplates are available. Multiple gear

pumps can also be built. If a variation

from the Standard Catalog Assemblies is

required, use the model codes on pages

10 through 18.

* 55.2 [3.37] 排量较高连续压力是 190 bar [2750 PSI]

** 46.7 [2.85] 排量较高间歇压力是 252 bar [3650 PSI]

L2系列齿轮泵元件能够组装成许多

The performance data in the table above and the following

graphs was collected using a mineral base oil with

a viscosity of 133 SUS at 49° C [120° F].

Intermittent - Intermittent operation, 10% of every minute.

选项配置，通用型设计使你能够组

装成满足你特殊要求的泵

** 51.1 [3.12] 排量较高间歇压力是 234 bar [3400 PSI]

** 55.2 [3.37] 排量较高间歇压力是 217 bar [3150 PSI]

/r] [1.30] [1.55] [1.78] [2.05] [2.33] [2.61] [2.85] [3.12] [3.37]

Max. Continuous† 248 248 248 248 248 248 224 207 190

Besides the Standard Catalog Assemblies,

The following performance graphs are representative of the series.

Model 25500 25501 25502 25503 25504 25505 25506 25507 25508

较工作温度 -29°C [-20°F]

较高进油口真空度在 82°C [180°F] 和额定转速下 6.0 In. Hg

＋连续－泵可以在这些额定值下连续工作。 ＋＋间歇－间歇工作，每分钟的10% 。

关于侧向载荷限制，请询问你的伊顿人。

* 46.7 [2.85] 排量较高连续压力是 224 bar [3250 PSI]

* 51.1 [3.12] 排量较高连续压力是 207 bar [3000 PSI]

多联泵输入扭矩限制:用于多联泵排量和压力组合的总扭矩不能过

轴的较大输入扭矩额定值。正确的公式是压力乘以排量再除以6.28。

旋转方向 逆时针或顺时针

安装法兰 SAE 2 螺栓 B

较高连续 压力 248 bar[3600 PSI]

较高间歇＋＋压力 276 bar[4000 PSI]

在连续压力下的较转速 750 RPM

进油口较高连续温度 107°C [225°F]

Pressure bar [PSI] [3600] [3600] [3600] [3600] [3600] [3600] [3250] [3000] [2750]

Max. Intermittent†† 276 276 276 276 276 276 252 234 217

Pressure bar [PSI] [4000] [4000] [4000] [4000] [4000] [4000] [3650] [3400] [3150]

Rated Speed (RPM) 3500 3000 3000 2750 2750 2500 2500 2500 2250

Continuous - pump may be run continuously at these ratings.

Displacement 21.3 25.4 29.2 33.6 38.2 42.8 46.7 51.1 55.2
