ASCO温系列电磁阀，8210G078LT

ASCO温系列电磁阀，8210G078LT

电 话：021-39529830转8009

手 机；18917074297

企业QQ；2880626083

邮箱；18917074297@163.com

联系人：郑娜

DC Cryogenic Valves: -320°F to 120°F (-196°C to 49°C)

All Liquid CO2 Valves: -75°F to 120°F (-59°C to 49°C)

Refer to Engineering Section for details.

• All suffix “LT” valves are degreased, cleaned, tested

free of moisture, and black light tested for hydrocarbons

• Liquid CO2 valves are suitable for remote mounting or

Optional: Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9.

(To order, add prefix “EF” to catalog number.)

See Optional Features Section for other available options

for direct mounting to the refrigerated component by

using four-hole bracket, provided

• “LT” suffix valves are built to control cryogenic fluids,

including liquid oxygen (-297°F/-181°C), liquid argon

(-303°F/-184°C), and liquid nitrogen (-320°F/-194°C)

AC Cryogenic Valves: -320°F to 150°F (-196°C to 66°C)

Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X.

液氩（-303°F / -184°C）和液氮（-320°F / -194℃）

•所有后缀“LT”阀门都脱脂，清洁，测试无水分，黑色测试碳氢化合物

•液态CO2阀门适用于远程安装或通过使用四孔支架直接安装到制冷部件

Body: Cryogenic Valves Brass

Body: LCO2 Valves Nickel-Plated Brass

Seals PTFE and/or Clad Copper/UR

•“LT”后缀阀用于控制温流体，包括液氧（-297°F / -181°C），

Disc PTFE/UR (8264 only)

Core and Plugnut 430F Stainless Steel or 49 FM Alloy

Core Spring 302 Stainless Steel

Shading Coil Copper

Seats Stainless Steel (8264 Series
