Thru-beam sensor, M18 threaded housing design,

DC voltage version

Thru-beam sensor, M18 threaded housing design, plastic housing,

front optical face, 20 m detection range, red light, light/dark on,

DC version, 2 PNP outputs, fixed cable

fixed cable, Efficient Line in a short

ffective detection range 0 ... 20 m

M18 plastic housing for standard applications, Very high detection range,

4 LEDs indicator for 360° visibility, Version with front optical face,

透射光束传感器，M18螺纹外壳设计，塑料外壳，前光学面，

20米检测范围，红灯，亮/暗开，直流版本，2个PNP输出，固定电缆

DC voltage version, Construction type(S2): Threading M18, Series: GLV18,

Housing diameter: M18, Housing: PC, Light type: modulated visible red light , 640 nm

Efficient Line in a short M18 plastic housing for standard applications

Very high detection range

flashes when falling short of the stability control ; OFF when light beam is interrupted

4 LEDs indicator for 360° visibility

Version with front optical face

MTTFd 630 a

Mission Time (TM) 20 a

Diagnostic Coverage (DC) 0 %

Indicators/operating means

Function indicator Receiver: LED yellow, lights up when light beam is free,

Threshold detection range 25 m

Light source LED

Light type modulated visible red light , 640 nm

Diameter of the light spot approx. 1300 mm at 25 m

Angle of divergence approx. 3 °

高效线路用于标准应用的短M18塑料外壳

非常高的检测范围

4个LED指示灯，用于360°可见度

带前光学面的版本

直流电压版本

Functional safety related parameters

plastic housing, front optical face, 20 m detection range,

red light, light/dark on, DC version, 2 PNP outputs,
