Compliance with standards and directives

Directive conformity

 EMC Directive 2004/108/EC EN 60947-5-2:2007+A1:2012

Standard conformity

Black/White difference (6 %/90 %) < 5 % at 150 mm

Diameter of the light spot approx. 10 mm at a distance of 150 mm

Angle of divergence approx. 4 °

Functional safety related parameters

MTTFd 600 a

Mission Time (TM) 20 a

Diagnostic Coverage (DC) 0 %

Indicators/operating means

Switching type The default setting is:

C/Q - BK: NPN normally open, PNP normally closed, IO-Link

Q2 - WH: NPN normally open, PNP normally closed

Signal output 2 push-pull (4 in 1)outputs,

 short-circuit protected, reverse polarity protected, overvoltage protected

Usage category DC-12 and DC-13

IEC 60947-5-2:2007 + A1:2012

Mechanical specifications

Deree of protection IP67 / IP69 / IP69K

Connection 2 m fixed cable

Material

Housing PC (Polycarbonate)

Optical face PMMA

IO-link interface for service and process data

Fuction indicator LED yellow:

constantly on - switch output active

constantly off - switch output inactive

Control elements Teach-In key

Electrical specifications

Operating voltage 10 ... 30 V DC

terface type IO-Link ( via C/Q = BK )

IO-Link Revision 1.1

Product standard EN 60947-5-2:2007+A1:2012

Miniature design with versatile mounting options

Multi Pixel Technology (MPT) - flexibility and adaptability

Reduction of device variety - several switch points within one sensor

Reliable detection of all surfaces, independent of color and structure

 Low sensitivity to target color

Switching diffuse mode sensor with measurement core t

echnology, 150 mm detection range, red light, IO-Link, 2 x push-pull output, 2 m fixed cable

General specifications

Detection range 5 ... 150 mm
