with high repetition accuracy, such

switching output is directly programmed

into the device using a

teach button; the IO-Link function is

programmed by means of a graphic

user interface in the controller. The

programming options in the two

operating modes are: cylinder switch

function, window comparator,

hysteresis comparator.

The IO-Link/switching output is therefore

the universal interface for simple

programming of routine application

functions without needing to evaluate

the analogue output.

as in press-fitting, screwing, riveting,

ultrasonic welding, good/bad

selection and other applications

它们是许多应用的方案，

尤其是那些涉及物体检测、

可编程 IO-Link 和或/开关输出

模拟输出 4 ... 20 mA

IO-Link

开关输出 NO 或 NC

位置测量范围 50, 80, 100, 125, 160 mm

on the piston stroke is required

过程监控（例如：厚度测量）、

磨损以及好坏检测的应用。

The SDAT-MHS is a position transmitter

which continuously records the

movement of the piston within the

sensing range and makes it available

as an output signal proportional to

the displacement.

电缆长度 0.3 m

电气接口, 4 针, M8x1 插头

设计用于 T 型槽

非接触式位置信号发送器可以在位置测

量范围内连续记录活塞的动作并转换成标

准化的模拟量电流或电压信号输出。

Position transmitters are used to

provide feedback on piston movement

in pneumatic drives. They are

situated between simple cylinder

switches and expensive displacement

encoders, both in terms of

price and complexity. They are the

ideal solution for applications in

which reliable analogue feedback

The sensing ranges are 50, 80, 100,

125 and 160 mm, making them

perfectly harmonised to the stroke of

the best-selling Festo cylinders.

The SDAT has a 4-20mA analogue

output, so it can be connected to

analogue inputs without accessories.

An IO-Link/switching output is available

as a second interface. There is

thus a choice between: switching

output 24 V or IO-Link operation. The
