Operate at low pressures: no minimum required; up to 15 psi

maximum differential.

• Normally Closed or Normally Open operation.

• Widely used for dispensing, collating, gas shutoff, vacuum

holding, and tank draining applications.

• Normally Open valve well suited for venting systems.

黄铜电磁阀是工业过程自动化控制系统用的执行器，

它在接受电控信号后能自动开启或关闭阀门，

Standard Voltages: 24, 120, 240, 480 volts AC, 60 Hz (or 110, 220 volts AC,

50 Hz), 6, 12, 24, 120, 240 volts DC. Must be specified when ordering. Other

voltages available when required.

实现对管道中流体介质的通断或流量调节控制，

从而对系统中的温度、流量、压力等参数进行自动调节或远程控制。

Body Brass 304 Stainless Steel

Seals and Disc NBR

Core Tube 305 Stainless Steel

Core and Plugnut 430F Stainless Steel

Core Spring 302 Stainless Steel

Shading Coil Copper Silver

Stem PA (Normally Open)

压操作：无需较要求; 高达15 psi较大差

•常闭或常开操作。

•广泛用于分配，整理，气体关闭，真空持有和罐排水应用。

•常开阀非常适合排气系统。

Approvals:

CSA certified. UL listed, as indicated. FM approved (Normally

Closed only except 8030G17 and 8030G67). Meets applicable

CE directives.

Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X.

Optional: Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9.

(To order, add prefix “EF” to catalog number.)
