Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X.

Optional: Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9.

(To order, add prefix “EF” to catalog number)

See Optional Features Section for other available options.

它是一种直动和先导式相结合的原理，当入口与出口没有压差时，

通电后，电磁力直接把先导小阀和主阀关闭件依次向上提起，阀门打开。

当入口与出口达到启动压差时，通电后，电磁力先导小阀，主阀下腔压力上升，

上腔压力下降，从而利用压差把主阀向上推开；

断电时，先导阀利用弹簧力或介质压力推动关闭件，向下移动，使阀门关闭。

Standard Voltages: 24, 120, 240, 480 volts AC, 60 Hz (or 110, 220 volts AC, 50 Hz).

6, 12, 24, 120, 240 volts DC. Must be specified when ordering.

Other voltages available when required.

特点：1.在真空、负压、零压时能正常工作，但通径一般不过25mm。

2.在零压差或真空、高压时亦可动作，但功率较大，要求必须水平安装。

Mounting bracket (suffix MB)

High Vacuum service (suffix VH; see Vacuum Section for more details.)

Oxygen service (suffix N)

Silicone Free (suffix SF)

Elastomers: FKM (suffix V), Ethylene Propylene (suffix E),

CR (suffix J), PTFE* (suffix T), Low Temp. NBR** (suffix A)

Note: *PTFE reduces pressure rating by 25% (i.e. 750 psi reduced to 560 psi)

**For Low Temp. NBR, fluid temperature range is -40°F to 167°F

Refer to Engineering Section for fluid and temperature compatibility.

1）常闭型，通电时电磁线圈产生足够的电磁力把运动部件（

由磁芯、阀杆、上下部的膜片/密封件构成）从阀座上提起，

阀门开启；断电时弹簧力把运动部件压在阀座上，阀门关闭。

2）常开型，动作方向与常闭型相反。

Reliable, proven design with high flows

• Small poppet valves for tight shutoff

• Wide range of elastomers for specialty service

• Mountable in any position

• Brass and stainless steel constructions
