Range hysteresis 1 % of the set operating distance

Temperature influence ± 1.5 % of full-scale value

Approvals and certificates

UL approval cULus Listed, General Purpose

CSA approval cCSAus Listed, General Purpose

CCC approval CCC approval / marking not required for products rated ≤36 V

Ambient conditions

Ambient temperature -25 ... 70 °C (-13 ... 158 °F)

Storage temperature -40 ... 85 °C (-40 ... 185 °F)

Mechanical specifications

Connection type Connector M12 x 1 , 5-pin

为了地检测困难目标物，大多数的漫反射模式传感器可以通过软件参数设置

转换为反射板模式。有的声波传感器从一开始就提供了反射板模式的传感器

0-level: -UB...+1 V

1-level: +4 V...+UB

input impedance: > 12 kΩ

synchronization pulse: ≥ 100 µs, synchronization interpulse period: ≥ 2 ms

Synchronization frequency

Common mode operation max. 40 Hz

Multiplex operation ≤ 40 Hz /n, n = number of sensors

Degree of protection IP67

Housing brass, nickel-plated

Transducer epoxy resin/hollow glass sphere mixture; foam polyurethane, cover PBT

Input type 1 program input,

声波传感器常用的模式是漫反射模式。单个声波传感器既是发射器又是接收器，并且通常包含相应的电子处理元件在同一个外壳内。

operating range 1: -UB ... +1 V, operating range 2: +4 V ... +UB

input impedance: > 4.7 kΩ; program pulse: ≥ 1 s

Output type 1 switch output PNP Normally open/closed , programmable

Rated operating current 200 mA , short-circuit/overload protected

Voltage drop ≤ 3 V

Repeat accuracy ≤ 1 %

Switching frequency max. 3 Hz

Ultrasonic sensor UB1000-18GM75-E5-V15

5 different output functions can be set

General specifications

声波传感器常用的模式是漫反射模式。单个声波传感器既是发射器又是接收器，并且通常包含相应的电子处理元件在同一个外壳内。

operating range 1: -UB ... +1 V, operating range 2: +4 V ... +UB

input impedance: > 4.7 kΩ; program pulse: ≥ 1 s

Output type 1 switch output PNP Normally open/closed , programmable

Rated operating current 200 mA , short-circuit/overload protected

Voltage drop ≤ 3 V

Repeat accuracy ≤ 1 %

Sensing range 70 ... 1000 mm

Adjustment range 90 ... 1000 mm

Dead band 0 ... 70 mm

Standard target plate 100 mm x 100 mm

Transducer frequency approx. 255 kHz

Response delay approx. 125 ms

Indicators/operating means

LED yellow indication of the switching state

flashing: program function object detected

LED red solid red: Error

red, flashing: program function, object not detected

Electrical specifications

Operating voltage 10 ... 30 V DC , ripple 10 %SS

No-load supply current ≤ 50 mA

Synchronization 1 synchronous connection, bi-directional
