产品描述：

electronics and over a standard signal output or a fi eld bus interface.

In the device two calibration curves can be stored,

型号 8709 是一台用于在工艺技术领域内测量液体流量的装置。

 MassFlowCommunicator software can be used for parameterisation and diagnosis.

然后通过一个标准信号输出端或一个现场总线接口被输出。

which the user is able to switch between.

The actual value supplied by the sensor is transmitted through the digital

在设备中，可以保存两个校准曲线，用户可在两者之间进行转换。

Type 8708 is an instrument for liquid fl ow control in process technology.

传感器提供的实际值会被发送到数字的电子设备中，

The device offers a particularly compact solution.

特点：

• Applicable for liquid flow measurement

介质里无移动部件

•  No moving parts in medium

可选的现场总线

High dynamic flow measurement

适合测量较大为 600 ml/min (36 l/h) 的液体量

up to 600 ml/min (36 l/h)

高动态流量测量装置

•  Fieldbus optional • Compact version

紧凑型结构

技术参数：

Accuracy ±1.5 % o.R. ±0.5 % F.S. Repeatability ±0.5 % F.S.

Turn-down ratio 1:10 Response time (t95%) < 500 ms Body material Stainless

15-pin plug M12 (PROFIBUS) 5-pin socket M12 (DeviceNet, CANopen) 5-pin plug

Operating voltage 24 V DC ± 10 % Residual ripple < 2 %

steel Housing PC (Polycarbonate) Sealing material FKM, EPDM, FFKM Port

connection G 1/8, NPT 1/8, G 1/4, NPT 1/4, sub-base Electrical Connection Sub-D

Full scale range (Qnom) 0.9 to 36 l/h (15 to 600 ml/min) re.

water Operating medium Clean and low viscous liquids Viscosity 0.4 to 4 cSt Max.

operating pressure (at inlet) Up to max. 10 barg; typical max.

2 barg Calibration medium Water (conversion to operating medium with correcting function)

 Medium temperature 10 to + 40 °C Ambient temperature  0 to + 55 °C
