先导阀

常闭，直动式

螺纹体，1/8和M10

Ø6毫米快插接头

产品特点

•双向数控先导阀为除尘器服务

•常闭直动

•坚固的黄铜锻造阀体结构

•专为面板安装

•结构紧凑，重量轻建设

•组件符合所有相关的EC指令

主体黄铜

芯管不锈钢

和plugnut不锈钢

弹簧不锈钢

底纹线圈铜

连接黑桃2个DIN-46244（A6.3x0.8）或

含铅线圈460毫米

OPTIONS

• Epoxy moulded leaded coils or coils with spade plug connector (3 x DIN-46244)

• Pipe connection E = Rp (ISO 7/1) or compression type fitting inlet

• Pilot valves can be equipped with explosion proof solenoids for

hazardous locations according to

"ATEX" and national standards

INSTALLATION

• The solenoid valves are open frame constructions, designed for panel

mount or stand alone and can be installed in any

position without affecting operation

• Recommended maximum panel thickness is 6,0 mm and panel passage Ø 20 mm

• Installation/maintenance instructions are included with each valve

• Replacement coils are available
