CPU data 400 MHz processor

Status displays LED

Electrical connection technology for I/O Socket strip, grid 3.5 mm

Resistance to vibration As per EN 61131-2

Resistance to shock As per EN 61131-2

Relative air humidity [%] 95, non-condensing

Protection class IP20

Electrical protection class III

Product weight [g] 200

Note on materials RoHS-compliant

Operating and environmental conditions CECC-LK CECC-D CECC-D-BA CECC-S

Operating voltage [V DC] 19.2 … 30 20.4 … 30

Nominal operating voltage DC [V] 24

Current consumption at 24 V DC [mA] 100

Max. power supply [A] 6 4.3 4.3 6

Ambient temperature [°C] 0 … 55

Storage temperature [°C] –25 … +70

CE marking To EU EMC Directive

Approval RCM trademark

c UL us - Listed (OL)

Certificate issuing authority UL E239998-D1001

Encoder inputs

Type CECC-LK CECC-D CECC-D-BA CECC-S

Number – – – 1

Resolution [bit] – – – 32

Signal range [V] – – – 5, differential (RS 422)

Max. input frequency [kHz] – – – 1000

Encoder supply voltage – – – 5 V DC (100 mA)
