销售美国ASCO353脉冲除尘阀，SCG353A043

销售美国ASCO353脉冲除尘阀，SCG353A043

电气特性

线圈绝缘等级F

连接器铲形插头（电缆直径6-10毫米）

连接器规范ISO 4400/ EN 175301-803，A型

电气安全IEC335

GENERAL

Differential pressure See «SPECIFICATIONS» [1 bar =100 kPa]

Maximum viscosity 65 cSt (mm2/s)

Response time 15 - 60 ms (3/8 to 3/4); 40 - 120 ms (1 to 1 1/2)

fl uids (✴) temperature range (TS) seal materials (✴)

air, inert gas, water, oil - 20°C to + 85°C NBR (nitrile)

电气外壳防护等级IP65模制（EN 60529）

标准电压DC（=）：24V - 48V

（其它电压和60赫兹应要求提供）AC（〜）：24V - 48V - 115V - 230V /50赫兹

MATERIALS IN CONTACT WITH FLUID

(✴) Ensure that the compatibility of the fl uids in contact with the materials is verifi ed

Body Brass

Core tube Stainless steel

Core and plugnut Stainless steel

Springs Stainless steel

Seat Brass

Seal, diaphragm & disc NBR

Disc holder (NO function) PA
